Name: TL955 Wheel Loader
Brand: Taijin Machinery
SKU: TJ-TL955-2026-HD
Rating: 4.8 (15 reviews)

TL955

Product Details

Product Data

Rated Load	5000kg
Overall Weight	16500kg
Bucket Width	2950mm
Rated Bucket Capacity	3m³
Maximum Tractive Force	152KN
Maximum Breakout Force	≥170KN
Maximum Grade Ability	30°
Maximum Dump Height	3150mm
Maximum Dump Reach	1250mm
Overall Dimension (L×W×H)	8085×2950×3450mm
Minimum Turning Radius	6150mm
Model	Weichai SteyrWD10G220E21
Type	lnline water cooling dry cylinder injection
No. of cylinder-bore/stroke	6－126×130mm
Rated Power	162kw
Maximum Torque	980N.m
Min Fuel-consume Ratio	≤215g/kw.h
Torque Converter	ZL50
Gearbox Model	planetary
Gear Shift	2forward shift 1reverse shift
Maximum Speed	38km/h
Main Reducing Spiral	Bevel gear grade 1reduction
Decelerating Model	Planetary reduction,grade 1
Wheel Base	3250mm
Wheel Tread	2250mm
Minimum Ground Clearance	460mm
System Working Pressure	18Mpa
Boom Lifting Time	5.95±0.2s
Total Time	10.95±0.5s
Fuel Tank Capacity	290L
Hydraulic Tank Capacity	250L
Function Of Leveling Automatically	Assembled
Service Brake	Air over hydraulic disc brake on 4 wheels
Parking Brake	Manual parking brake
Type Specification	23.5-25
Front Tyre Pressure	0.4Mpa
Rear Tyre Pressure	0.35Mpa
